Performance Racing

TPED Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	N2 Capacity	Weight	Thickness
	cuin	lbs	in	in	psi	cuft	lbs	in
LW-90-0.80-166-TPED	48.82	1.76	3.54	8.98	2407	4.63	2.42	0.193
LW-90-1.10-166-TPED	67.13	2.42	3.54	10.63	2407	6.36	2.79	0.193
LW-90-1.20-166-TPED	73.23	2.64	3.54	12.28	2407	6.94	3.17	0.193
LW-90-1.30-166-TPED	79.33	2.86	3.54	13.11	2407	7.52	3.34	0.193
LW120-1.70-166-TPED	103.74	3.74	4.72	10.55	2407	9.83	5.37	0.26
LW120-3.40-166-TPED	207.48	7.48	4.72	18.35	2407	19.66	8.45	0.26
LW140-6.70-166-TPED	408.86	14.74	5.51	25.16	2407	38.75	14.98	0.299
LW184-10.00-166-TPED	610.24	22	7.24	23.07	2407	57.83	23.58	0.398
LW184-13.40-166-TPED	817.72	29.48	7.24	29.49	2407	77.49	29.35	0.398

SKU	Water Capacity	Diameter	Length	Service Pressure	N2 Capacity	Weight	Thickness
	liters	mm	mm	bar	liters	kgs	mm
LW-90-0.80-166-TPED	0.8	90	228	166	131.1	1.1	4.9
LW-90-1.10-166-TPED	1.1	90	270	166	180.2	1.27	4.9
LW-90-1.20-166-TPED	1.2	90	312	166	196.6	1.44	4.9
LW-90-1.30-166-TPED	1.3	90	333	166	213	1.52	4.9
LW120-1.70-166-TPED	1.7	120	268	166	278.5	2.44	6.6
LW120-3.40-166-TPED	3.4	120	466	166	557	3.84	6.6
LW140-6.70-166-TPED	6.7	140	639	166	1097.7	6.81	7.6
LW184-10.00-166-TPED	10	184	586	166	1638.3	10.72	10.1
LW184-13.40-166-TPED	13.4	184	749	166	2195.3	13.34	10.1

DOT Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	N2 Capacity	Weight	Thickness
	cuin	lbs	in	in	psi	cuft	lbs	in
LF-111.3-2015-1.20-DOT	73.23	2.64	4.38	8.43	2015	5.81	3.5	0.203
LF-111.3-2015-1.30-DOT	79.33	2.86	4.38	8.94	2015	6.29	3.65	0.203
LF-111.3-2015-1.70-DOT	103.74	3.74	4.38	10.98	2015	8.23	4.25	0.203

ï»¿SKU	Water Capacity	Diameter	Length	Service Pressure	N2 Capacity	Weight	Thickness
	liters	mm	mm	bar	liters	kgs	mm
LF-111.3-2015-1.20-DOT	1.2	111.3	214	139	164.6	1.59	5.15
LF-111.3-2015-1.30-DOT	1.3	111.3	227	139	178.3	1.66	5.15
LF-111.3-2015-1.70-DOT	1.7	111.3	279	139	233.2	1.93	5.15
