Refillable TPED Aluminum Gas Cylinder (T1)
ImperialMetric
SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material |
---|---|---|---|---|---|---|---|---|---|
cuin | lbs | in | in | psi | lbs | lbs | in | ||
LW90-0.80-166-TPED | 48.82 | 1.76 | 3.54 | 8.98 | 2407 | 1.20 | 2.42 | 0.193 | AA 6061 |
LW90-1.10-166-TPED | 67.13 | 2.42 | 3.54 | 10.63 | 2407 | 1.65 | 2.79 | 0.193 | AA 6061 |
LW90-1.20-166-TPED | 73.23 | 2.64 | 3.54 | 12.28 | 2407 | 1.80 | 3.17 | 0.193 | AA 6061 |
LW90-1.30-166-TPED | 79.33 | 2.86 | 3.54 | 13.11 | 2407 | 1.94 | 3.34 | 0.193 | AA 6061 |
LW120-1.70-166-TPED | 103.74 | 3.74 | 4.72 | 10.55 | 2407 | 2.54 | 5.37 | 0.260 | AA 6061 |
LW120-3.40-166-TPED | 207.48 | 7.48 | 4.72 | 18.35 | 2407 | 5.09 | 8.45 | 0.260 | AA 6061 |
LW140-6.70-166-TPED | 408.86 | 14.74 | 5.51 | 25.16 | 2407 | 10.02 | 14.98 | 0.299 | AA 6061 |
LW184-10.00-166-TPED | 610.24 | 22.00 | 7.24 | 23.07 | 2407 | 14.96 | 23.58 | 0.398 | AA 6061 |
LW184-13.40-166-TPED | 817.72 | 29.48 | 7.24 | 29.49 | 2407 | 20.05 | 29.35 | 0.398 | AA 6061 |
SKU | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material |
---|---|---|---|---|---|---|---|---|
liters | mm | mm | bar | kgs | kgs | mm | ||
LW90-0.80-166-TPED | 0.80 | 90 | 228 | 166 | 0.54 | 1.10 | 4.90 | AA 6061 |
LW90-1.10-166-TPED | 1.10 | 90 | 270 | 166 | 0.75 | 1.27 | 4.90 | AA 6061 |
LW90-1.20-166-TPED | 1.20 | 90 | 312 | 166 | 0.82 | 1.44 | 4.90 | AA 6061 |
LW90-1.30-166-TPED | 1.30 | 90 | 333 | 166 | 0.88 | 1.52 | 4.90 | AA 6061 |
LW120-1.70-166-TPED | 1.70 | 120 | 268 | 166 | 1.16 | 2.44 | 6.60 | AA 6061 |
LW120-3.40-166-TPED | 3.40 | 120 | 466 | 166 | 2.31 | 3.84 | 6.60 | AA 6061 |
LW140-6.70-166-TPED | 6.70 | 140 | 639 | 166 | 4.56 | 6.81 | 7.60 | AA 6061 |
LW184-10.00-166-TPED | 10.00 | 184 | 586 | 166 | 6.80 | 10.72 | 10.10 | AA 6061 |
LW184-13.40-166-TPED | 13.40 | 184 | 749 | 166 | 9.11 | 13.34 | 10.10 | AA 6061 |
Refillable DOT Aluminum Gas Cylinder (T1)
ImperialMetric
SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material |
---|---|---|---|---|---|---|---|---|---|
cuin | lbs | in | in | psi | lbs | lbs | in | ||
EVO-LW-133-3.40-1800-DOT | 207.48 | 7.48 | 5.24 | 14.17 | 1800 | 5.09 | 6.80 | 0.215 | AA 6061 |
EVO-LW-175-6.70-1800-DOT | 408.86 | 14.74 | 6.89 | 16.73 | 1800 | 10.02 | 14.04 | 0.283 | AA 6061 |
EVO-LW-175-10.00-1800-DOT | 610.24 | 22.00 | 6.89 | 23.46 | 1800 | 14.96 | 18.28 | 0.203 | AA 6061 |
EVO-LW-203-13.40-1800-DOT | 817.72 | 29.48 | 7.99 | 23.62 | 1800 | 20.05 | 25.04 | 0.328 | AA 6061 |
SKU | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material |
---|---|---|---|---|---|---|---|---|
liters | mm | mm | bar | kgs | kgs | mm | ||
EVO-LW-133-3.40-1800-DOT | 3.40 | 133 | 360 | 124 | 2.31 | 3.09 | 5.47 | AA 6061 |
EVO-LW-175-6.70-1800-DOT | 6.70 | 175 | 425 | 124 | 4.56 | 6.38 | 7.19 | AA 6061 |
EVO-LW-175-10.00-1800-DOT | 10.00 | 175 | 596 | 124 | 6.80 | 8.31 | 7.19 | AA 6061 |
EVO-LW-203-13.40-1800-DOT | 13.40 | 203 | 600 | 124 | 9.11 | 11.38 | 8.34 | AA 6061 |
Refillable TPED Steel Gas Cylinder (T1)
ImperialMetric
SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material | Base shape |
---|---|---|---|---|---|---|---|---|---|---|
cuin | lbs | in | in | psi | lbs | lbs | in | |||
BXT104-3.40-210-2.55-A | 207.48 | 7.48 | 4.09 | 20.79 | 3045 | 5.09 | 8.95 | 0.100 | 34CrMo4 | Concave |
BXT154-6.70-166.7-3.14-A | 408.86 | 14.74 | 6.06 | 18.86 | 2418 | 10.02 | 17.86 | 0.124 | 34CrMo4 | Concave |
BXT154-10.00-166.7-3.14-A | 610.24 | 22.00 | 6.06 | 26.61 | 2418 | 14.96 | 22.95 | 0.124 | 34CrMo4 | Concave |
BXT154-13.40-166.7-3.14-A | 817.72 | 29.48 | 6.06 | 34.61 | 2418 | 20.05 | 28.18 | 0.124 | 34CrMo4 | Concave |
SKU | Water Capacity | Diameter | Length | Service Pressure | N2O Capacity | Weight | Thickness | Material | Base shape |
---|---|---|---|---|---|---|---|---|---|
liters | mm | mm | bar | kgs | kgs | mm | |||
BXT104-3.40-210-2.55-A | 3.40 | 104 | 528 | 210 | 2.31 | 4.07 | 2.55 | 34CrMo4 | Concave |
BXT154-6.70-166.7-3.14-A | 6.70 | 154 | 479 | 166.7 | 4.56 | 8.12 | 3.14 | 34CrMo4 | Concave |
BXT154-10.00-166.7-3.14-A | 10.00 | 154 | 676 | 166.7 | 6.80 | 10.43 | 3.14 | 34CrMo4 | Concave |
BXT154-13.40-166.7-3.14-A | 13.40 | 154 | 879 | 166.7 | 9.11 | 12.81 | 3.14 | 34CrMo4 | Concave |
