Refillable TPED Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | ||
| LW60-0.40-166-TPED | 24.41 | 0.88 | 2.36 | 9.45 | 2407 | 2.31 | 1.01 | 0.126 | AA 6061 |
| LW60-0.50-166-TPED | 30.51 | 1.10 | 2.36 | 11.26 | 2407 | 2.89 | 1.19 | 0.126 | AA 6061 |
| LW90-0.80-166-TPED | 48.82 | 1.76 | 3.54 | 8.98 | 2407 | 4.63 | 2.42 | 0.193 | AA 6061 |
| LW90-1.00-166-TPED | 61.02 | 2.20 | 3.54 | 10.63 | 2407 | 5.78 | 2.79 | 0.193 | AA 6061 |
| LW90-1.50-166-TPED | 91.54 | 3.30 | 3.54 | 14.76 | 2407 | 8.67 | 3.72 | 0.193 | AA 6061 |
| LW120-2.00-166-TPED | 122.05 | 4.40 | 4.72 | 11.93 | 2407 | 11.57 | 5.92 | 0.260 | AA 6061 |
| LW120-2.67-166-TPED | 162.93 | 5.87 | 4.72 | 15.00 | 2407 | 15.44 | 7.13 | 0.260 | AA 6061 |
| LW120-3.00-166-TPED | 183.07 | 6.60 | 4.72 | 16.50 | 2407 | 17.35 | 7.72 | 0.260 | AA 6061 |
| LW140-5.00-166-TPED | 305.12 | 11.00 | 5.51 | 19.53 | 2407 | 28.91 | 12.03 | 0.299 | AA 6061 |
| LW203-13.40-166-TPED | 817.72 | 29.48 | 7.99 | 25.28 | 2407 | 77.49 | 31.72 | 0.441 | AA 6061 |
| LW203-14.00-166-TPED | 854.33 | 30.80 | 7.99 | 26.22 | 2407 | 80.96 | 32.76 | 0.441 | AA 6061 |
| LW203-15.00-166-TPED | 915.36 | 33.00 | 7.99 | 27.80 | 2407 | 86.75 | 34.47 | 0.441 | AA 6061 |
| LW203-16.00-166-TPED | 976.38 | 35.20 | 7.99 | 29.37 | 2407 | 92.53 | 36.17 | 0.441 | AA 6061 |
| LW203-17.00-166-TPED | 1037.40 | 37.40 | 7.99 | 30.94 | 2407 | 98.31 | 37.88 | 0.441 | AA 6061 |
| LW203-18.00-166-TPED | 1098.43 | 39.60 | 7.99 | 32.52 | 2407 | 104.10 | 39.60 | 0.441 | AA 6061 |
| LW203-19.00-166-TPED | 1159.45 | 41.80 | 7.99 | 34.09 | 2407 | 109.88 | 41.32 | 0.441 | AA 6061 |
| LW203-20.00-166-TPED | 1220.48 | 44.00 | 7.99 | 35.67 | 2407 | 115.66 | 43.03 | 0.441 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LW60-0.40-166-TPED | 0.40 | 60 | 240 | 166 | 65.50 | 0.46 | 3.20 | AA 6061 |
| LW60-0.50-166-TPED | 0.50 | 60 | 286 | 166 | 81.90 | 0.54 | 3.20 | AA 6061 |
| LW90-0.80-166-TPED | 0.80 | 90 | 228 | 166 | 131.10 | 1.10 | 4.90 | AA 6061 |
| LW90-1.00-166-TPED | 1.00 | 90 | 270 | 166 | 163.80 | 1.27 | 4.90 | AA 6061 |
| LW90-1.50-166-TPED | 1.50 | 90 | 375 | 166 | 245.70 | 1.69 | 4.90 | AA 6061 |
| LW120-2.00-166-TPED | 2.00 | 120 | 303 | 166 | 327.70 | 2.69 | 6.60 | AA 6061 |
| LW120-2.67-166-TPED | 2.67 | 120 | 381 | 166 | 437.40 | 3.24 | 6.60 | AA 6061 |
| LW120-3.00-166-TPED | 3.00 | 120 | 419 | 166 | 491.50 | 3.51 | 6.60 | AA 6061 |
| LW140-5.00-166-TPED | 5.00 | 140 | 496 | 166 | 819.10 | 5.47 | 7.60 | AA 6061 |
| LW203-13.40-166-TPED | 13.40 | 203 | 642 | 166 | 2195.30 | 14.42 | 11.20 | AA 6061 |
| LW203-14.00-166-TPED | 14.00 | 203 | 666 | 166 | 2293.60 | 14.89 | 11.20 | AA 6061 |
| LW203-15.00-166-TPED | 15.00 | 203 | 706 | 166 | 2457.40 | 15.67 | 11.20 | AA 6061 |
| LW203-16.00-166-TPED | 16.00 | 203 | 746 | 166 | 2621.30 | 16.44 | 11.20 | AA 6061 |
| LW203-17.00-166-TPED | 17.00 | 203 | 786 | 166 | 2785.10 | 17.22 | 11.20 | AA 6061 |
| LW203-18.00-166-TPED | 18.00 | 203 | 826 | 166 | 2948.90 | 18.00 | 11.20 | AA 6061 |
| LW203-19.00-166-TPED | 19.00 | 203 | 866 | 166 | 3112.80 | 18.78 | 11.20 | AA 6061 |
| LW203-20.00-166-TPED | 20.00 | 203 | 906 | 166 | 3276.60 | 19.56 | 11.20 | AA 6061 |
Refillable DOT Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | |||
| LF-81.5-2216-0.70-DOT | 42.72 | 1.54 | 3.21 | 9.45 | 2216 | 3.73 | 1.94 | 0.163 | AA 6061 | |
| LF-81.5-2216-1.00-DOT | 61.02 | 2.20 | 3.21 | 12.20 | 2216 | 5.33 | 2.40 | 0.163 | AA 6061 | |
| LF-111.3-2015-1.40-DOT | 85.43 | 3.08 | 4.38 | 9.45 | 2015 | 6.78 | 3.81 | 0.203 | AA 6061 | |
| LF-111.3-2015-1.70-DOT | 103.74 | 3.74 | 4.38 | 10.98 | 2015 | 8.23 | 4.25 | 0.203 | AA 6061 | |
| LF-133.4-2216-3.90-DOT | 237.99 | 8.58 | 5.25 | 16.93 | 2216 | 20.79 | 9.02 | 0.265 | AA 6061 | |
| LF-133.4-2216-4.00-DOT | 244.10 | 8.80 | 5.25 | 17.28 | 2216 | 21.32 | 9.17 | 0.265 | AA 6061 | |
| LF-133.4-2216-4.55-DOT | 277.66 | 10.01 | 5.25 | 19.25 | 2216 | 24.25 | 10.08 | 0.265 | AA 6061 | |
| LF-133.4-2216-5.90-DOT | 360.04 | 12.98 | 5.25 | 24.17 | 2216 | 31.45 | 12.45 | 0.265 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LF-81.5-2216-0.70-DOT | 0.70 | 81.5 | 240 | 153 | 105.70 | 0.88 | 4.15 | AA 6061 |
| LF-81.5-2216-1.00-DOT | 1.00 | 81.5 | 310 | 153 | 151.00 | 1.09 | 4.15 | AA 6061 |
| LF-111.3-2015-1.40-DOT | 1.40 | 111.3 | 240 | 139 | 192.10 | 1.73 | 5.15 | AA 6061 |
| LF-111.3-2015-1.70-DOT | 1.70 | 111.3 | 279 | 139 | 233.20 | 1.93 | 5.15 | AA 6061 |
| LF-133.4-2216-3.90-DOT | 3.90 | 133.4 | 430 | 153 | 588.90 | 4.10 | 6.74 | AA 6061 |
| LF-133.4-2216-4.00-DOT | 4.00 | 133.4 | 439 | 153 | 604.00 | 4.17 | 6.74 | AA 6061 |
| LF-133.4-2216-4.55-DOT | 4.55 | 133.4 | 489 | 153 | 687.00 | 4.58 | 6.74 | AA 6061 |
| LF-133.4-2216-5.90-DOT | 5.90 | 133.4 | 614 | 153 | 890.90 | 5.66 | 6.74 | AA 6061 |
Refillable TPED Steel Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | |||
| BXT104-2.00-210-2.55-A | 122.05 | 4.4 | 4.09 | 13.46 | 3045 | 14.63 | 6.78 | 0.100 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 183.07 | 6.6 | 4.09 | 18.70 | 3045 | 21.95 | 8.23 | 0.100 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 183.07 | 6.6 | 4.57 | 15.24 | 3045 | 21.95 | 8.71 | 0.102 | 34CrMo4 | Concave |
| BXT116-5.00-210-2.58-A | 305.12 | 11.0 | 4.57 | 23.66 | 3045 | 36.58 | 10.74 | 0.102 | 34CrMo4 | Concave |
| BXT136-5.00-210-3.01-A | 305.12 | 11.0 | 5.35 | 18.35 | 3045 | 36.58 | 14.19 | 0.119 | 34CrMo4 | Concave |
| BXT140-5.00-300-4.50-T | 305.12 | 11.0 | 5.51 | 18.19 | 4350 | 52.40 | 18.04 | 0.177 | 34CrMo4 | Convex |
| BXT136-8.00-210-3.01-A | 488.19 | 17.6 | 5.35 | 27.28 | 3045 | 58.53 | 19.21 | 0.119 | 34CrMo4 | Concave |
| BXT140-8.00-300-4.50-T | 488.19 | 17.6 | 5.51 | 27.99 | 4350 | 83.61 | 27.61 | 0.177 | 34CrMo4 | Convex |
| BXT154-8.00-210-3.40-A | 488.19 | 17.6 | 6.06 | 22.13 | 3045 | 58.53 | 20.26 | 0.134 | 34CrMo4 | Concave |
| BXT154-8.00-166.7-3.14-A | 488.19 | 17.6 | 6.06 | 21.93 | 2418 | 46.46 | 19.87 | 0.124 | 34CrMo4 | Concave |
| BXT136-10.00-210-3.01-A | 610.24 | 22.0 | 5.35 | 33.23 | 3045 | 73.16 | 22.59 | 0.119 | 34CrMo4 | Concave |
| BXT154-10.00-210-3.40-A | 610.24 | 22.0 | 6.06 | 27.09 | 3045 | 73.16 | 23.83 | 0.134 | 34CrMo4 | Concave |
| BXT154-10.00-166.7-3.14-A | 610.24 | 22.0 | 6.06 | 28.07 | 2418 | 58.08 | 22.95 | 0.124 | 34CrMo4 | Concave |
| BXT154-14.00-210-3.40-A | 854.33 | 30.8 | 6.06 | 36.34 | 3045 | 102.43 | 30.34 | 0.134 | 34CrMo4 | Concave |
| BXT154-14.00-166.7-3.14-A | 854.33 | 30.8 | 6.06 | 36.02 | 2418 | 81.31 | 29.13 | 0.124 | 34CrMo4 | Concave |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Nitrogen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | |||
| BXT104-2.00-210-2.55-A | 2.00 | 104 | 342 | 210 | 414.50 | 3.08 | 2.55 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 3.00 | 104 | 475 | 210 | 621.80 | 3.74 | 2.55 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 3.00 | 116 | 387 | 210 | 621.80 | 3.96 | 2.58 | 34CrMo4 | Concave |
| BXT116-5.00-210-2.58-A | 5.00 | 116 | 601 | 210 | 1036.30 | 4.88 | 2.58 | 34CrMo4 | Concave |
| BXT136-5.00-210-3.01-A | 5.00 | 136 | 466 | 210 | 1036.30 | 6.45 | 3.01 | 34CrMo4 | Concave |
| BXT140-5.00-300-4.50-T | 5.00 | 140 | 462 | 300 | 1484.40 | 8.20 | 4.50 | 34CrMo4 | Convex |
| BXT136-8.00-210-3.01-A | 8.00 | 136 | 693 | 210 | 1658.00 | 8.73 | 3.01 | 34CrMo4 | Concave |
| BXT140-8.00-300-4.50-T | 8.00 | 140 | 711 | 300 | 2368.60 | 12.55 | 4.50 | 34CrMo4 | Convex |
| BXT154-8.00-210-3.40-A | 8.00 | 154 | 562 | 210 | 1658.00 | 9.21 | 3.40 | 34CrMo4 | Concave |
| BXT154-8.00-166.7-3.14-A | 8.00 | 154 | 557 | 166.7 | 1316.20 | 9.03 | 3.14 | 34CrMo4 | Concave |
| BXT136-10.00-210-3.01-A | 10.00 | 136 | 844 | 210 | 2072.50 | 10.27 | 3.01 | 34CrMo4 | Concave |
| BXT154-10.00-210-3.40-A | 10.00 | 154 | 688 | 210 | 2072.50 | 10.83 | 3.40 | 34CrMo4 | Concave |
| BXT154-10.00-166.7-3.14-A | 10.00 | 154 | 713 | 166.7 | 1645.20 | 10.43 | 3.14 | 34CrMo4 | Concave |
| BXT154-14.00-210-3.40-A | 14.00 | 154 | 923 | 210 | 2901.60 | 13.79 | 3.40 | 34CrMo4 | Concave |
| BXT154-14.00-166.7-3.14-A | 14.00 | 154 | 915 | 166.7 | 2303.30 | 13.24 | 3.14 | 34CrMo4 | Concave |
